Harley Davidson XL 1200N Nightster

Make Model	Harley Davidson XL 1200N Nightster
Year	2011 - 12
Engine	Fur stroke, 45� V-Twin Evolution� Valve Train Pushrod-operated, OHV, 2 valves per cylinder
Capacity	1199 cc / 73.2 cu-in
Bore x Stroke	88.8 x 96.8 mm
Cooling System	Air cooled
Compression Ratio	9.7:1
Lubrication	Dry-sump
Induction	Electronic Sequential Port Fuel Injection (ESPFI)
Ignition	Digital CDI
Starting	Electric
Max Torque	107.3 Nm / 79 lb-ft @ 4000 rpm
Clutch	Wet 9-plate
Transmission	5 Speed
Final Drive	Belt
Primary Drive	Chain, 57/38 ratio
Gear Ratio	1st 9.315 2nd 6.653 3rd 4.948 4th 4.102 5th 3.517
Frame	Mild steel, tubular frame, circular sections, cast junctions Swingarm Mild steel rectangular tube sections, stamped junctions, MIG welded
Front Suspension	39mm Forks
Rear Suspension	Coil-over, dual-adjustable preload
Front Brakes	Single 292mm disc 2 piston calipers
Rear Brakes	Single 292mm disc 1 piston caliper
Front Tyre	100/90B19 57H
Rear Tyre	150/80B16 77H
Rake	30.5�
Trail	117 mm / 4.8 in
Dimensions	Length 2179 mm / 85.8 in
Wheelbase	1519 mm / 59.8 in
Seat Height	Laden  653 mm  /  25.7 in Unladen 683 mm  /  26.9 in
Ground Clearance	100 mm / 4.7 in
Dry Weight	252 kg / 335 lbs
Wet Weight	301 kg /665 lbs
Fuel Capacity	12.5 Litres / 3.3 US gal

Ever since its introduction in 2007, the Nightster� model has prowled the streets with a deep, menacing growl. Low, dark and aggressive, it brought a styling attitude to the Sportster� family that had not been seen before � a raw, Dark Custom� bike that delivers a 1200cc knockout punch.

Chopped front and rear fenders. Side-mounted license plate. Combined stop/turn/tail lights. Low 25.3-inch seat height. Old-school front fork gaiters. Raw-boned graphics and a unique finish on its V-Twin Evolution� engine. And just for good measure, black throughout. With its gritty, no-nonsense look, the Nightster� model is the motorcycle for those who want Sportster� performance coupled with an attitude you don�t normally find on such a nimble machine.

Sportster� Models: Personalization and Power

The six 2012 Harley-Davidson� Sportster� models range from the affordable Dark CustomTM roadster-inspired Iron 883TM motorcycle to the track-inspired performance of the XR1200XTM bike. Each Sportster� model offers the heartbeat of an authentic American V-Twin engine and pace-setting style and performance.

Back for its first full year of production is the Sportster� 1200 Custom bike, the motorcycle that introduced the Web-based H-D1TM Bike Builder factory customization process. Using Bike Builder, Customers can personalize their 1200 Custom motorcycle with the seat, handlebar, foot control, wheel, security, paint, and engine finish options of their choice, which are then installed right at the Factory. Even more Retailer-installed accessories can be added, and viewed, on the Bike Builder site. The Customer can then print out a description of their bike and bring it to a Harley-Davidson� Retailer where they can review the motorcycle with trained staff, select additional accessories to be installed by the Retailer to further customize the motorcycle, and then place an order. Customers can expect to be riding their new bike in as little as four weeks from the time an order is placed with an authorized Harley-Davidson� Retailer.

All  Sportster� models will have Michelin� ScorcherTM tires with a tread pattern designed, tested and styled specifically for the Sportster� motorcycle to provide an ideal grip, an even wear and a longer life. Fifteen Sportster� paint options include seven new colour choices for 2012. Side covers will be finished in either Gloss Black or Denim Black to match the finish on other bodywork. The Forty-EightTM model will have a new tank graphic.

Harley-Davidson� Sportster� Models

" SuperLowTM
" Iron 883TM
" Sportster� 1200 Custom
" NightsterTM
" Forty-EightTM
" XR1200XTM

NEW Black side covers to match bodywork finish
NEW Michelin� Scorcher� �31� front and rear tires
NEW Paint color options
� Medium-gray powder-coated engine with polished covers
� Chrome exhaust with slash-cut mufflers
� Low front and rear suspension
� Classic 3.3-gallon fuel tank
� Black, Laced Steel wheels with chrome spokes and black hubs
� Chopped front fender with black brackets and lightening holes
� Chopped rear fender with black supports
� Belt guard with lightening holes
� Black fork sliders and black fork gaiters
� Sportster� Classic solo seat
� Black hand and foot controls
� Side-mounted license plate
� Combination stop/turn/tail lights
� Black headlamp body with black visor and satin trim ring
� Black low-rise handlebar and black riser
� Evolution� V-Twin powertrain with Electronic Sequential Port Fuel Injection (ESPFI)
� Rubber-mounted powertrain to reduce vibration
� 5-speed transmission
� Dual staggered exhaust
� Handlebar-mounted electronic speedometer
� Disc brakes
� Mid-mounted foot controls
� Optional Harley-Davidson� Smart Security System with hands-free security fob
� Optional Original Equipment Custom Color paint program
